Refrigeration Shaded Pole Motor is a motor specially designed to drive fans or compressors in refrigeration systems. According to the drawings, physical pictures and data sheets you provided, the following is the product description of this refrigeration shaded pole motor:
1. Product Description
Model: YZF Series
Type: Refrigeration Shaded Pole Motor
Application: Suitable for various refrigeration equipment, such as air conditioners, refrigerators, cold storage, etc.
2. Main Features:
High efficiency: The use of shaded pole technology ensures that the motor can operate efficiently under various working conditions.
Durability: The motor housing is made of high-quality materials with good corrosion resistance and wear resistance, extending the service life.
Low noise: The optimized motor design and precise manufacturing process ensure low noise when the motor is running.
Reliability: After strict quality control and testing, it ensures that the motor can operate stably in various environments.
Easy to install: The motor is compact in design and easy to install, suitable for various refrigeration equipment.
3. Technical parameters:

Voltage: 110~120V or 220-240V
Frequency: 50/60Hz
Input power: 33W to 120W
Output power: 5W to 34W
Current: 0.25A to 1.50A
Speed: 1300 r/min or 1450 r/min or 1550 r/min
Fan blade diameter: Φ200mm, Φ230mm, Φ250mm, Φ300mm
4. Dimensions and installation:
Dimensions: According to the drawings, the dimensions of the motor are 84mm x 67mm x 70mm (length x width x height).
Mounting hole spacing: 26mm
Shaft diameter: Φ71.4mm
5. Operation and maintenance:
Operation: The motor should be operated at the specified voltage and frequency to avoid overload and voltage fluctuations.
Maintenance: Check the running status of the motor regularly, clean the motor housing and heat sink, and ensure that the motor is well ventilated.
